　　　 [XCAR Information Original]　

　　　　As we all know, engine, gearbox and chassis are the three key components of an automobile, and they are also the core technologies that a vehicle manufacturer must master. In the last article, we talked about the achievements of independent brands in engine research and development. In the early stage, independent manufacturers mostly used imitation and purchase to obtain engine technology. Compared with engines, the lack of self-owned brands in automatic gearbox technology is more obvious. The research and development of automatic gearbox is difficult, with high technical content, and it is difficult to imitate in a short period of time, which makes it impossible for self-owned brands to develop automatic gearboxes that can be applied on a large scale at present.

Technical blockade! Automatic gearbox inventory of dozens of autonomous vehicles

　　　　There is a great demand for automatic gearbox in the market, and the demand is still growing, which makes independent brands can only obtain automatic gearbox by purchasing. However, the lack of their own technology and the restrictions of foreign gearbox manufacturers also lead to the limited choice of automatic gearbox for independent brands, and most of the products they carry do not have much technical advantage. Today, what we are going to introduce to you are several automatic gearboxes that are common in our own brand models.

　　　● AT gearbox

　　　　Manual gearbox is mainly composed of gears and shafts, which produce variable speed and torque through different gear combinations; The automatic gearbox AT is composed of hydraulic torque converter, planetary gear and hydraulic control system, which realizes variable speed and torque by means of hydraulic transmission and gear combination.

　　　　Hydraulic torque converter is the most characteristic component of AT gearbox, which is composed of pump wheel, turbine and guide wheel, and directly inputs engine power to transmit torque and clutch action. Pump wheel and turbine are a pair of working combinations, which are like two fans placed opposite each other. The wind from one active fan will drive the blades of the other passive fan to rotate, and the flowing air — — Wind becomes the medium of kinetic energy transfer.

　
Hydraulic torque converter of conventional automatic gearbox

　　　　If air is replaced by liquid as the medium to transfer kinetic energy, the pump wheel will drive the turbine to rotate through the liquid, and then a guide wheel is added between the pump wheel and the turbine to improve the transfer efficiency of the liquid. Because the range of automatic speed change and torque change of hydraulic torque converter is not large enough and the efficiency is low, several rows of planetary gears are connected in series behind the turbine to improve the efficiency, and the hydraulic control system will automatically control the planetary gears with the change of engine work, thus realizing automatic gear shift.

　　　　Self-owned brand AT gearbox provider 1: Aisin Seiki

　　　　Manufacturer profile:Japan Aisin Seiki Co., Ltd. is one of the world’s top 500 enterprises and the ninth largest auto parts manufacturer in the world. Founded in 1949, the company is the main supplier of Toyota auto parts, and its auto parts manufacturing technology is world-famous.

　
Aisin Seiki provides AT gearboxes for most domestic independent manufacturers.

　　　　Aisin Japan Co., Ltd. is an import and export trading company specializing in auto parts, auto warranty equipment, hardware, mechanical equipment, power tools and other products. About 95% of the company’s sales come from auto parts, but the company also manufactures refrigeration equipment and cutting machines, as well as consumer products such as beds and sewing machines. Aisin Seiki has subsidiaries in the United States, Europe, Asia and Australia.

　　　　Roewe 750

　　　　Aisin Triple-Mode five-speed automatic manual transmission

　　　　Named KV6, the 2.5 V6 engine is mounted on the Roewe 750, SAIC’s first self-owned brand model. It is said that it is of the same ancestry as the Land Rover Freelander in the UK, and it is also made of aviation-grade all-aluminum material in terms of materials, which not only reduces the weight by 40%, but also improves the efficiency by 20%, and can explode 135KW at 6500 rpm. With EVIC-III intelligent dual-valve variable air intake control technology, the maximum power is 135KW/6500rpm and the maximum torque is 240Nm/4000rpm.

　
SAIC Roewe 750

Roewe 750 gearbox comes from Aisin.

　　　　Matching this V6 engine is a five-speed Triple-Mode intelligent adaptive automatic gearbox from Aisin-Warner, Japan. There are three modes: normal mode, sports mode and snow mode. In sports mode, you can obviously feel the rise of power level.

　　　　Roewe 550/MG6

　　　　Aisin 5-speed Tiptronic gearbox

　　　　Roewe 550 is equipped with a 1.8L ordinary aspirated engine and a 1.8T turbocharged engine respectively. The 1.8T all-aluminum engine can output the maximum power of 118kw horsepower at 5500 rpm and the maximum torque of 215Nm at 2500-4500 rpm. Numerically, the Roewe 550 lags behind the Volkswagen engine with the same 1.8T engine in terms of torque output.

Roewe 550 is equipped with Tiptronic five-speed automatic manual transmission provided by Aisin.

　　　　Roewe 550 automatic transmission adopts 5-speed Tiptronic automatic manual transmission made by Aisin, which has excellent performance, both the advantages of simple operation of automatic transmission and the advantages of arbitrary manual transmission. However, in actual driving, Roewe 550 is more comfortable, and the power and gearbox are relatively mild, without too intense control.

　　　　In addition, MG6, which is on the same platform as Roewe 550, is also equipped with Japanese Aisin Tiptronic five-speed automatic manual transmission. After the driver hangs in manual mode, he can also manually shift gears through the shift paddles behind the steering wheel to improve driving pleasure.

　　　　Roewe 350

　　　　Aisin 4-speed Multi-Mode automatic gearbox

　　　　The 1.5L naturally aspirated engine equipped on the Roewe 350 uses a silent timing chain and a VTi multi-angle continuous variable timing system (variable timing of intake and exhaust), with a maximum power of 80kw/6000rpm and a maximum torque of 135Nm/4500rpm. With 5-speed manual transmission and 4-speed automatic transmission.

Roewe 350

Roewe 350 gearbox is equipped with a four-speed gearbox provided by Aisin.

　　　　Roewe 350 is equipped with the 4-speed Multi-Mode automatic gearbox of Aisin Japan, which can be adjusted and corrected according to the driver’s driving habits and road conditions to ensure the smoothness when shifting gears.

Aisin is the main supplier of AT gearbox with its own brand.

　　　　Pentium B50

　　　　Aixin AQ250 series six-speed automatic manual transmission

　　　　Pentium B50 is equipped with Volkswagen’s 4-cylinder 8-valve single overhead camshaft engine, and its technology is old. The maximum power of 74kW/6000rpm and the maximum torque of 145Nm/3800rpm are a little behind in the same displacement. However, this Volkswagen engine, which is also equipped on Jetta and Sagitar, has more than 2.3 million units in China, which means that the maintenance and repair of this engine is more convenient and economical.

Pentium B50 is equipped with 6-speed automatic manual transmission provided by Aisin.

　　　　Matching this engine is an Aisin AQ250 series six-speed automatic manual transmission, which is easy to be mistaken for the same one used by sagitar and Bora. Although both are six-speed automatic manual transmission, the Pentium B50 is not Tiptronic six-speed automatic manual transmission, but Aisin’s six-speed automatic manual transmission. This gearbox matches Volkswagen’s 1.6L engine very well.

　　　　Pentium B70

　　　　Aisin 5-speed automatic manual transmission

　　　　Pentium B70 and mazda 6 belong to the same platform model, with 2.3L and 2.0L powertrains. The 2.0L engine is the main engine, equipped with the same 2.0L engine as mazda 6, with the maximum power of 146 HP /6500rpm and the maximum torque of 183Nm/4000rpm, and with S-VT variable valve timing and VIS variable intake manifold technology.

B70 is equipped with a 5-speed automatic manual transmission provided by Aisin.

　　　　Like mazda 6, the Pentium B70 is equipped with a 6-speed manual transmission or a 5-speed automatic manual transmission, which is provided by Aisin Seiki.

　　　　Guangzhou automobile chuanqi

　　　　Aisin 5-speed automatic manual transmission

　　　　GAC Chuanqi officially rolled off the assembly line on September 3rd. The first batch of GAC Chuanqi off the assembly line was equipped with a 2.0L engine. This engine did not adopt the direct injection technology previously speculated by the media, but was an ordinary naturally aspirated model with a maximum power of 110kw/6300rpm. Then GAC will launch Chuanqi’s 1.8L model.

Chuanqi will carry a variety of models from 1.8 to 2.4L.

5-speed automatic manual transmission provided by Aisin.

　　　　Chuanqi will match the 5-speed manual or 5-speed automatic manual transmission, instead of the AMT gearbox previously speculated by the media. The 5-speed manual transmission is also from Fiat, which is the original manual transmission of Alfa Romeo 166, while the 5-speed automatic manual transmission is from Aisin Seiki, Japan, which is also a very mature and reliable product.

　　　　Dongfeng fengshen S30

　　　　Aisin Step-gate four-speed intelligent automatic transmission

　　　　Fengshen S30’s 1.6L engine equipped with PSA, a partner, has stable and reliable quality. The maximum power reaches 78KW, and the torque output reaches 85% of the maximum at 1,500 rpm, 90% at 2,000 rpm, and reaches the maximum torque of 142Nm at 4,000 rpm.

Dongfeng fengshen S30

Dongfeng fengshen S30 gearbox comes from Aisin.

　　　　Fengshen S30 automatic gearbox is equipped with Japanese Aisin Step-gate four-speed intelligent automatic transmission, which is calibrated by German GIF company. The automatic gearbox has mature technology, can automatically learn and remember the driver’s driving habits, and can provide the desired shift mode at any time.

　　　　Chang ‘an Yuexiang

　　　　Aisin DSS 4-speed automatic transmission

　　　　Changan Yuexiang is equipped with a 1.5L displacement engine, with a maximum power of 72kw and a maximum torque of 137Nm, and its maximum torque can be output at 3500 rpm.

Yuexiang is equipped with Aisin DSS 4-speed automatic transmission

　　　　Yuexiang’s automatic transmission model matches the original Aisin DSS 4-speed automatic transmission imported from Japan. The biggest feature of this gearbox is that the electronic control replaces the traditional hydraulic control, which realizes life-long maintenance-free and no need to change lubricating oil, and has longer service life, stronger reliability, better ride comfort and economy.

　　　　Brilliance Junjie cross

　　　　Aixin 4-speed automatic gearbox

　　　　Junjie Cross1.5L and 1.6L engines are available. 1.5L engine is 4a151.5l in-line 4-cylinder dual overhead camshaft VVT-i variable valve technology engine independently developed by Brilliance Auto. The rated power of this engine is 75kw/5500-6000rpm, and the maximum torque can reach 135Nm/4500rpm. The 1.6L engine is a Mitsubishi 4G18 1.6L engine from dongan power, with a power of 74kw/6000rpm and a maximum torque of 138Nm/4500rpm.

Junjie cross is equipped with Aisin 4-speed automatic transmission.

　　　　Junjie Cross is equipped with Aisin 4-speed automatic transmission, with automatic manual function. Compared with the four-speed automatic gearbox used in the self-owned brand models below 100,000 yuan, its shift smoothness is at the leading level.

Self-owned brand model equipped with Aisin AT gearbox

　　　　Independent brand AT gearbox supplier II: Mitsubishi Corporation

　　　　On February 1st, 2010, the first auto automatic transmission imported from Japan’s Mitsubishi technology was officially rolled off the assembly line in Dongan Mitsubishi. At this point, Dongan Mitsubishi will be able to provide automobile engines, manual gearboxes and automatic gearboxes.

Mitsubishi engines are widely used in self-owned brands.

　　　　The first phase of the automatic gearbox project of Dong ‘an Mitsubishi has been completed, which can produce 4AT and 5AT gearboxes, and has the technical space to upgrade to 6AT, with an annual production capacity of 150,000 units, meeting the power transmission demand of engines with displacement of 1.3L－2.4L.

　　　　Brilliance Junjie FRV

　　　　Mitsubishi 4-speed automatic manual transmission

　　　　Junjie FRV adopts Mitsubishi 4G18S and 4G13S power engines in the whole car series, of which the maximum power of 4G13S engine is 62.5KW/6000rpm. The maximum torque output is 108/4500 Nm/rpm. It will be equipped with a 5-speed manual transmission and a 4-speed automatic manual transmission from Mitsubishi.

Brilliance Junjie FRV

Mitsubishi’s 4-speed automatic gearbox

　　　　Self-owned brand AT gearbox supplier 3: Japan JATCO Company

　　　　JATCO is the third largest manufacturer of automatic gearbox design in the world. Founded in 1943, JATCO is one of the three largest suppliers of automatic gearbox in the world.

　　　　Its business covers Europe, Asia and America, and mainly provides automatic gearboxes for most mainstream vehicle manufacturers such as Nissan, Mitsubishi, Mazda, BMW, Volkswagen, Land Rover, Jaguar, Kia, Hyundai, Daewoo, Changan Ford and Brilliance, with an annual supply of more than 4 million units. Jeep Guide, Dongfeng Nissan Sylphy and Ford Mondeo are all equipped with gearboxes produced by JATCO.

　　　　Byd F3

　　　　JATCO four-speed automatic gearbox

　　　　BYD F3 is equipped with 1.6L and 1.5L power, and the platinum version is equipped with Mitsubishi 4G15S inline four-cylinder /16-valve, using Mitsubishi MVV vertical vortex lean combustion technology. The maximum power can reach 78 kW at 6000 rpm and the peak torque of 134Nm at 4500 rpm. Match 5-speed manual or 4-speed automatic gearbox.

Byd F3

A 4-speed automatic gearbox produced by JATCO.

　　　　BYD F3 automatic transmission uses the original imported 4-speed automatic gearbox produced by Japanese manufacturer JATCO. The four-speed gearbox produced by JATCO company has mature and reliable technology, and its matching with Mitsubishi engine is excellent. Mitsubishi Corporation has completed all the vehicle calibration work for the powertrain, and its power performance, fuel economy and maneuverability have reached a high level.

　　　　Independent brand AT gearbox supplier 3: Hyundai Motor

　　　　In 1967, Zheng Zhouyong founded Hyundai Motor Company. After more than 40 years of development, it has become the largest automobile manufacturer in South Korea and entered the ranks of world-famous automobile companies.

　　　　Chery Ruiqi G5

　　　　Hyundai 5f25at gearbox

　　　　The Ruiqi G5 automatic transmission model will also use the 2.0TCI engine independently developed by Chery, with a maximum power of 116Kw/5000rpm and a peak torque of 250Nm. The 2.0TGDI turbocharged direct injection engine has a maximum power of 144kw/5500rpm and a maximum torque of 290Nm/1800rpm. Due to the large output torque, only the 6-speed manual gearbox is matched.

　
Ruiqi G5 is equipped with a 5-speed automatic transmission provided by Hyundai.

　　　　The 2.0TCI engine of Ruiqi G5 matches the 5AT gearbox provided by Hyundai. This automatic gearbox is 5F25, with five forward gears and the maximum transmission torque of 250Nm.

　　 Independent brand AT gearbox supplier 4: Geely (independent research and development)

　　　　Geely panda

　　　Geely JL-ZA 142 fully automatic 4-speed gearbox

　　　　Panda uses 1.0L and 1.3L displacement engines. The 1.0L engine has a maximum output power of 50KW, a peak torque of 88Nm when the speed reaches 3600 rpm, and a lifting power of 52kw. CVVT technology is adopted. The other 1.3L engine, code-named MR479Q, has a maximum power of 63kW and a maximum torque of 110N·m, which is basically equivalent to the same displacement engine on the market.

Geely panda

A 4-speed automatic gearbox independently developed by Geely.

　　　　The automatic version of Panda is equipped with JL-ZA142 fully-automatic 4-speed gearbox independently developed by Geely. It was successfully developed by Geely after three years of huge investment. It not only won the first prize of scientific and technological progress in China automobile industry, but also won the evaluation of "advanced level of international similar products". This is also the only automatic gearbox with independent intellectual property rights in China. Independent research and development makes panda automatic transmission models have great advantages in price.

Other AT gearbox suppliers

　　　●　continuously variable transmission

　　　　CVT has no specific gear, and its operation is similar to that of automatic gearbox, but the change of speed ratio is different from the trip stop process of automatic gearbox, but continuous, so the power transmission is continuous and smooth.

　　　　The advantages of CVT are as follows: First, the power output of CVT gearbox is linear, and the shifting frustration caused by it also disappears, which is very smooth in actual driving. Secondly, the transmission system of CVT can have infinitely many gears in theory, and the gear ratio, speed ratio and the balance of performance, fuel consumption and exhaust emission in the traditional transmission system are easier to achieve. Finally, the mechanical efficiency and fuel economy of CVT transmission are much better than ordinary automatic transmission, second only to manual transmission, and the fuel economy is much better.

continuously variable transmission

　　　　So CVT has no shortcomings? The answer is no, first of all, when starting or accelerating, CVT steel belt or belt is prone to slip, which will affect the power transmission, thus affecting the acceleration feeling. Secondly, CVT steel belt or belt material requirements are relatively high. Although CVT has a simple structure, if it fails, it is generally not a minor problem. This will affect the use of car owners and increase maintenance costs.

continuously variable transmission

　　　　One supplier of CVT gearbox: Punch Company of Belgium

　　　　Belgian Punch (Bang Qi) Company is a German ZF company specializing in the production of transmissions (including CVT).

　　　　Under the premise that international automobile manufacturers have blocked the key technologies in China, Bang Qi is also the only overseas manufacturer that provides CVT gearboxes for domestic independent brands, and the gearboxes provided are not the most advanced products at present, and the actual performance is average.

　　　　Southeast V3 Lingyue

　　　　Punch VT2 transmission

　　　　V3 Lingyue is equipped with 4A91 engine produced by Shenyang Aerospace Mitsubishi, and uses the latest MIVEC variable valve timing system of Mitsubishi Motors, which truly reaches the international advanced level of natural inhalation, with a maximum power of 120 HP and a maximum torque of 143Nm/4000rpm.

V3 Lingyue CVT version adopts intelligent CVT continuously variable gearbox with 6-speed manual gear.

　　　　The V3 Lingyue automatic transmission is equipped with a new generation VT2 CVT CVT produced by Punch, a famous transmission company. The transmission adopts the technology, technology and production line of Punch company completely, with 6-speed automatic manual transmission and various intelligent modes such as snow and sports, so that drivers can choose the most suitable driving mode according to their own driving habits and climatic factors.

　　　　Great Wall Tengyi C30/ Xuanli/Lingao

　　　　Punch VT2 transmission

　　　　Great Wall Tengyi C30, Xuanli and Lingao are all equipped with GW4G15 engine. GW4G15 engine is an all-aluminum gasoline engine developed by Great Wall Motor, which adopts double overhead camshaft, 4 cylinders and 16 valves, plastic intake manifold and VVT technology. With a maximum power of 77kW and a maximum torque of 138Nm, this engine can easily achieve Euro IV emission.

Tengyi C30

Tengyi C30 is equipped with CVT gearbox provided by Bang Qi.

　　　　Tengyi C30 and CVT continuously variable transmission carried by Xuanli and Lingao are internationally renowned original imported products from PUNCH, Belgium. It is worth mentioning that this type of CVT has also been applied to the old Mini Cooper, and its value has increased by 27.80% compared with that of 4AT transmission at 0-100km/h, 19.30% at 80-120km/h and 18% at 100-140 km/h.

　　　　Emgrand EC7

　　　　Punch VT2 transmission

　　　　Emgrand EC718 is powered by Geely’s JL-4G18 CVVT engine with a displacement of 1.8L The maximum power is 102kW (139HP) /6200rpm and the maximum torque is 172Nm/4200rpm.

Geely emgrand EC718

　　　　The CVT gearbox matched with Emgrand EC7 1.8L engine is a VT2 CVT continuously variable transmission from Belgian Punch (Bang Qi) company, which has three modes: manual (6-speed), sports and economy (normal).

　　　　BYD G3

　　　　Punch VT2 transmission

　　　　BYD G3 has four models with 1.5L and 1.8L displacement. The 1.5L model adopts BYD473QB and Mitsubishi 4G15S champion engines independently developed by BYD, the 1.8L model adopts BYD483QA engine independently developed, and the 1.8L automatic transmission model adopts the newly developed CVT continuously variable gearbox, with the maximum output power of 90kw at 6000 rpm and the maximum torque of 160Nm at around 3700 rpm.

BYD G3 is equipped with CVT gearbox provided by Bang Qi.

　　　　BYD G3 uses a CVT transmission of VT2 type in Bang Qi. Its technical feature is that it can simulate a 6-speed manual transmission and also has a sport mode.

　　　　CVT gearbox supplier II:Jiang Lu Rong da

　　　　Hunan Jianglu Rongda Vehicle Transmission Co., Ltd. was established in November 2003. It was established by Hunan Jianglu Machinery Group, Hunan Xicheng Industrial Group and Northern Transmission Company on the basis of the original Hunan Rongda Automobile Electronic Technology Co., Ltd., with a registered capital of 88 million yuan. It is a high-tech company specializing in the development, production and technical services of continuously variable transmission (CVT) of cars in China.

　　　　Lifan 620

　　　　Lifan 620 CVT still uses the lf479q2 1.5L engine produced by Lifan, with a maximum power of 69kW and a maximum torque of 128Nm at 3500 rpm.

Lifan 620

Lifan 620 gearbox is provided by Jianglu Rongda.

　　　　The steel belt, the core technology of CVT gearbox in lifan 620, comes from Bosch. Compared with the ordinary version of AT gearbox, equipped with CVT technology, it can improve power by 10% and save fuel consumption by 10%-15%, with a fuel consumption of 7.5L per 100 kilometers.

Self-owned brand models equipped with CVT gearbox

　　　　●AMT gearbox

　　　　Automatic mechanical transmission (AMT) is a new type of transmission that electronically controls the traditional dry clutch and manual gear transmission to realize automatic shifting, and its control process basically simulates the driver’s operation. According to the driver’s intention, the electronic control part of AMT gearbox can automatically control the clutch and shift process. More complicated, we don’t need to go into details. In fact, we can imagine the shift process of AMT in this way. His clutch and shift mechanism are controlled by electronic parts, and the shift will be automatic naturally.

　
Electric control device and hydraulic actuator of AMT

　　　　The biggest advantage of AMT gearbox is that it does not need to make too much changes to the existing manual gearbox, and its technical structure is relatively simple, and the cost is not too high for manufacturers. In fact, AMT is a manual gearbox with electronically controlled clutch and shift program, so it is the same dry clutch as manual transmission, so the transmission force is more direct and the fuel consumption is more economical. The ordinary AT gearbox adopts hydraulic "clutch", which will have some losses in energy transmission and slightly higher fuel consumption.

AMT is somewhat similar to an automatic manual transmission.

　　　　Of course, AMT has obvious shortcomings, that is, the shift quality is not high and it is prone to frustration. If you don’t step on the accelerator, the car won’t move forward even if you shift into D gear. This is somewhat different from the ordinary AT gearbox.

　　　　AMT gearbox supplier: Ma Ruili.

　　　　Manetti-Ma Ruili Group is one of the members of the world’s top 500 Italian FIAT GROUP, with a history of more than 90 years. Manetti Ma Ruili, headquartered in Corbetta, Milan, is a multinational group company engaged in the research, development, design and production of automobile parts, systems and components in the automotive industry, and is in a leading position in the design and manufacture of automobile parts and high-tech systems.

Manietti Ma Ruili, a subsidiary of Fiat, which produces AMT, has established a joint venture in Shanghai.

　　　　Tianjin FAW Weizhi

　　　　Ma Ruili Freechoice AMT

　　　　The VIOS 1.3L and 1.5L models are equipped with Toyota engines code-named 8A and 5A respectively, but only the sedan 1.5L automatic flagship model is an automatic transmission model, equipped with Toyota’s 5A+ engine. Although the technology is not advanced, the maximum power of 75kW/6000rpm and the maximum torque of 130Nm/4400rpm are more than enough to propel VIOS’s 1-ton body.

Weizhi

Weizhi is equipped with an AMT semi-automatic gearbox provided by Ma Ruili.

　　　　Weizhi automatic gear matches an AMT semi-automatic gearbox provided by Ma Ruili. This AMT automatic manual transmission has five forward gears, and P gear is cancelled, followed by "left, middle and right arrangement", with N gear and R gear on the far right, D gear in the middle, and a lever slot on the far left to switch between "automatic" and "manual" modes. Its disadvantage is that the shift impact is obvious and the ride comfort is not as good as that of the common automatic gearbox.

　　　　qiruiqq

　　　 Ma Ruili AMT

　　　　At the end of 2009, Chery launched two 1.0L models equipped with AMT gearbox, which also increased the number of models equipped with AMT gearbox in Chery QQ3 from the original two to four, with displacement of 1.0L and 1.1L.. The maximum power and torque of the 1.1L engine are 68 horsepower /6000rpm and 90Nm/3500-4000rpm respectively.

Chery QQ3

Chery QQ3 is equipped with AMT semi-automatic gearbox provided by Ma Ruili.

　　　　Chery QQ3 AMT model is equipped with a complete set of computer-controlled hydraulic shift system designed and manufactured by Italian Ma Ruili company, which can simulate the driving actions of excellent drivers and choose the best shift timing. According to official data of Chery, AMT model not only saves about 13% fuel than traditional automatic cars, but also saves about 9% fuel than similar manual cars.

Self-owned brand models equipped with AMT gearbox

　　 Extended reading:Real kung fu? Shantou? Detailed explanation of six high-end autonomous engines

　　　　Engine is the heart of a car, and it is also one of the core technologies of a car. A car manufacturer can not build seats, tires or multimedia systems, and even a gearbox can be obtained by purchasing. But what is certain is that no international automobile enterprise even introduces engines by purchase. Engine research and development has become the most invested and enthusiastic research and development project of automobile manufacturers, and it can also be regarded as one of the main signs to measure a manufacturer’s technical strength.

Shantou? Real kung fu? Detailed explanation of six high-end autonomous engines

　　　　The research and development of self-owned brand engines started from scratch, from imitation to independent innovation. Although there is still a big gap with the international level, there are also many excellent products in just over ten years. If you can’t remember which engines are available at the moment, don’t worry. Below we will present and introduce these independent research and development achievements to you.

　　　　Chery 2.0TGDI: Turbocharged Direct Injection Engine in Independent Brand

　　　　Vehicle models: Ruiqi G5 and Ruiqi G6.

　　　　Technical Keywords: Turbocharging, Direct Injection, Variable Valve Timing

　　　　In a word: Turbocharged direct injection technology is no longer the patent of Volkswagen, and Chery’s icebreaking finally made these technologies go down the altar and return to the public.

　　　　Chery’s progress in engine research and development is obvious to all. At first, it jointly developed its own ACTECO engine with AVL of Austria. This series of engines are technically quite satisfactory, and there is not much advanced technology applied, and the power output is also very general. However, ACTECO engine laid the foundation for Chery to develop more advanced engines.

Ruiqi G5 2.0TGDI

　　　　During this year’s Beijing Auto Show, Chery launched the Ruiqi G5 equipped with a 2.0TGDI engine. In order to promote this engine, Chery spared no expense to hire Messi to endorse it. Regardless of the final influence, this turbocharged direct injection engine is still worthy of recognition.

Chery 2.0TGDI engine

　
Turbocharger with intercooler (left) Real shot of 2.0TGDI engine (right)

　　　　The 2.0TGDI engine of Ruiqi G5 has a maximum power of 144kw/5500rpm and a maximum torque of 290Nm/1800rpm. Several technologies, such as direct injection GDI in gasoline cylinder, turbocharged intercooling TCI and variable valve timing VVT, are applied. Previously, Chery also launched a 2.0TCI engine with a maximum power of 116Kw/5000rpm and a peak torque of 250Nm. From the data. The 2.0TGDI engine has obvious advantages.

The 2.0TCI engine of Ruiqi G5.

　　　　The 2.0TSI engine carried by Volkswagen Magotan has a maximum power of 147kw/5000-6000rpm and a peak torque of 280Nm/1800-5000rpm. From the data point of view, the power output of Chery 2.0TGDI engine is almost the same, but in terms of reliability and practicality, Chery 2.0TGDI still needs to stand the test of time.

2.0TGDI engine output characteristic curve

　　　　The maximum torque of the 2.0GTDI engine reaches 290Nm, which exceeds the maximum bearing torque of the modern 5AT gearbox of 250Nm, so it is only equipped with a 6-speed manual gearbox, while the 2.0TCI model is equipped with a 6-speed manual gearbox and a 5-speed automatic gearbox.

　
Ruiqi G5

　　　　The body size of Ruiqi G5 2.0TGDI is 4717/1794/1473mm and the wheelbase is 2700mm. Ruiqi G5 adopts the front and rear suspension design of front double wishbone and rear multi-link, and the British Lotus Company participates in the whole process of adjusting the chassis, which can achieve a good balance in sports and comfort.

　
Ruiqi G6 will be equipped with a 2.0TGDI engine.

　　　　In addition, the 2.0TCI engine is also mounted on the Ruiqi G6. The length, width and height of the Ruiqi G6 are 4968mm, 1845mm and 1526mm； respectively. The body size parameters surpass the mainstream B-class cars, such as New Camry, Magotan and even the Eight-Generation Accord, and the 2820mm span is an absolute leader in the wheelbase that reflects comfort. The G6 is equipped with two high-performance engines, namely a 2.0TCI intercooled turbocharged engine and a 3.0 V six-cylinder engine.

　　[car home Information] The 2023 Guangzhou Auto Show is about to begin. The team in front of the museum in car home first photographed the new cars that will be launched/pre-sold/listed at this auto show, and now 13 new cars have been exposed in advance. It is worth mentioning that according to the current statistics, the number of new cars at this auto show has exceeded 100! Let’s take a sneak peek together!

● (|) coupe

　　On the eve of the Guangzhou Auto Show in 2023, the team of car home’s museum exploration team photographed the suspected brand-new Mercedes-Benz CLE coupe. As a new product combining mercedes benz c-class coupe with E-class coupe, Mercedes-Benz CLE has inherited the beautiful body structure of coupe, including hardtop version and convertible version, with a wheelbase of 2865mm, which is more advantageous than competitors such as BMW 4 Series and Audi A5.

　　In terms of appearance, let’s look at the previous real shots. Although Mercedes-Benz CLE retains the front styling design of mercedes benz c-class and E-class coupes, the new digital headlights have their own unique style, and the double-layer LED eyebrows inside make the new car look very spirited. The ribs on the engine compartment cover stretch strongly, and the black lattice starlight decoration details on the front bumper are in place, which further enhances the sense of fighting.

　　The side of the car body is the essence of CLE. Combining the design styles of C-class and E-class coupes, the waistline full of strength and the smooth Coupe roof curve are combined at the tail, which makes it look very elegant. The new CLE has a length, width and height of 4850/1860/1428 (coupe) /1430 (convertible coupe) mm, a wheelbase of 2865mm, and 18-to 20-inch rims, which bring further dynamic vitality to elegance.

　　In the rear part, the CLE taillight group changes obviously, which is different from the current C-class and E-class. It is more like learning from the S-class style. The rounded shape matches the curved red light strip, and the black plaque runs through the middle, making the visual effect more youthful.

　　In the interior part, the design style similar to this generation of mercedes benz c class makes people feel friendly. The new car is equipped with a 12.3-inch full LCD digital instrument and an 11.9-inch central control panel. If you look closely at the angle of the central control panel, it is also inclined to the driver by 6 degrees, which is convenient for the driver to operate. The third-generation MBUX intelligent human-computer interaction system applies the newly developed compatibility layer, and is equipped with more third-party in-vehicle applications to realize a richer content ecology.

　　The front integrated sports seat specially designed for CLE coupe and convertible coupe provides 7-zone massage function. Pull the elegant Nappa leather pull ring, and the new "EASY-ENTRY" function can fold the front seat forward, which is convenient for passengers to step into the rear space. The 64-color active ambient light provides a variety of ambience themes. The Burmester Voice of Berlin 3D surround sound system is equipped with two speakers at the headrest position of each seat. The total number of speakers in the whole car is 17 with Dolby panoramic sound to restore the ultimate acoustic effect.

　　In terms of power, the current top model Mercedes CLE 450 4MATIC is equipped with M256 3.0-liter twin-turbocharged inline six-cylinder engine, with a maximum power of 381 HP, a peak torque of 500 Nm and an acceleration time of 4.4 seconds at 0-100 km/h.. CLE 300 4MATIC is equipped with M254 2.0T engine, with maximum power of 258 HP, peak torque of 400 Nm, and acceleration time of 0-100km/h of 6.2 seconds. CLE 200, an entry-level gasoline version, is also equipped with a 2.0T engine, with a maximum power of 204 HP and an acceleration time of 7.5 seconds from 0 to 100 km/h. The whole system comes standard with 48V ISG intelligent motor system.

　　The new CLE coupe provides a sports suspension system, which can reduce the body height by 15mm. In addition, the new car also provides an active steering system for rear wheels, as well as intelligent driving assistance functions such as intelligent navigation distance limit, active lane keeping, speed limit assistance and intelligent parking.

● A new generation of Mercedes-Benz E-Class

　　On November 14th, the reporting team in front of car home photographed a new generation of Mercedes-Benz E-Class real cars near the exhibition hall. At the same time, according to previous information, the car will be listed during the auto show.

　　The new generation of Mercedes-Benz E-Class has a more recognizable front face design, and the headlight shape reminds us of the former "peanut lamp". The new car still provides a large standard version and a vertical standard version, which respectively reflect the sports and luxury styles. Among them, the large standard version uses a lattice grid inside the net, which looks close to the electric EQ series.

　　The new car has a slender side design, which is the same as that of the previous generation. Instead of directly lengthening the door, it has a C-pillar triangular window similar to that of Maibakh, reflecting the distinguished atmosphere of the extended version. This generation of models uses a hidden door handle, and at the same time has a "meteor glimpse" light carpet and LED star emblem spotlights. The drag coefficient of the new car is reduced to 0.23Cd. The design of the rear of the car echoes the front of the car. The bottom of the light group is wavy, and the internal light group adopts Mercedes-Benz Xinghui design, which is full of ceremony. In other respects, it is quite satisfactory.

　　The length, width and height of the long-axis model are 5092/1880/1493mm respectively, and the wheelbase reaches 3094mm, which is 133mm longer than that of the standard-axis model. In the power part, the domestic long-axis model will be equipped with M254 2.0T engine, and the maximum power of E 260 L model is 204 horsepower. The maximum power of the E 300 L model is 258 horsepower.

● Mercedes -AMG S 63 E PERFORMANCE

　　On the eve of Guangzhou Auto Show in 2023, the team of car home’s museum exploration team photographed the real car of AMG S 63 E PERFORMANCE. This car is a high-performance model based on Mercedes-Benz S-Class, equipped with a plug-in hybrid system composed of V8 engine and motor.

　　AMG S 63 E PERFORMANCE adopts the iconic waterfall grille of AMG family. The large-size air intakes on both sides surrounded by the blackened vertical grille make the front of the car look very domineering, and the headlights are also very sharp. The huge trident star emblem on the grille is covered by camouflage.

　　Viewed from the side, the 21-inch AMG forged rim complements the AMG side skirt, and the red brake calipers further render the fighting atmosphere. The square bilateral exhaust pipes at the rear of the car are matched with large-size diffusers, all of which release the aggressive momentum of AMG models and remind the rear car that it is a high-performance beast.

　　In terms of power, the new car will be equipped with a 4.0T twin-turbocharged V8 engine and a rear motor. The comprehensive output power of the whole power system can reach 803 HP (590 kW), the maximum torque can reach an astonishing 1,430 Nm, and the acceleration time from 0 to 96 km/h is only 3.2 seconds. After the AMG driving kit is selected, the top speed can reach 290 km/h. In addition, the new car has a power battery capacity of 13.1 kWh and a pure battery life of 33 kilometers. At the same time, it is also equipped with AMG adaptive air suspension, AMG active roll stabilization system, AMG dynamic engine mount, active rear wheel steering and many other cutting-edge technologies.

● brand newdomestically-builtsantafe

　　On the eve of the opening of Guangzhou Auto Show, car home’s team in front of the museum suspected to have photographed a brand-new domestic Shengda. Although the car was wrapped in a car coat, the rim was the same as the previous overseas version. According to previous news, the new car will officially make its debut at Guangzhou Auto Show.

　　Combined with the previous news, the new car will adopt a brand-new design concept of Open for More, and the overall recognition is more square and hard-core than the old models. Specifically, the car uses a narrow strip grille with a central penetrating light strip, which greatly improves the visual layering of the car. At the same time, the addition of H-style daytime running lights greatly enhances the recognition of the car.

　　Viewed from the side, the car adopts angular and slightly convex front and rear wheel eyebrows, and with the dense spoke wheel rim shape, it makes this car fashionable and hard-core. At the same time, the car also adopts the popular suspended roof design with black roof rack, which enhances the practicality of the vehicle and enhances the layering.

　　In terms of the tail, the car adopts a brand-new design shape and tends to be vertical, which makes this car have a somewhat cross-border taste. At the same time, it does not adopt the popular through taillight design, but the rectangular taillight group is decorated with H element, which makes it have good recognition.

　　In the interior part, the overall shape echoes the appearance, adopting bold straight lines, and at the same time, the mainstream standard technology configuration is also readily available. The new car is equipped with two 12.3-inch penetrating screens, a three-spoke multi-function steering wheel, a penetrating air-conditioning outlet and a 6.6-inch touch screen below, which further optimizes the convenience of driving while enhancing the sense of fashion. At the same time, the car also adopts the popular wireless fast charging configuration of dual mobile phones, and adds the design of air guide strips to reduce the fever problem of mobile phones. As can be seen in the details, most of the interiors are covered with leather, and the air outlet of the air conditioner and the door panel are also decorated with wooden decorative panels, which set off a tough and advanced cockpit feeling with the penetrating atmosphere lights.

　　In the power part, the new car will be equipped with a hybrid system of a 2.5-liter turbocharged four-cylinder engine and a 1.6-liter turbocharged matching motor. The maximum power of the 2.5L engine is 277 horsepower, which is matched with an 8-speed dual-clutch automatic transmission, and can choose a front-wheel drive or four-wheel drive model.

● New Elantra N

　　On the eve of the Guangzhou Auto Show, which opened on November 17th, the modern new Elantra N real car appeared. The car had been pre-sold, the pre-sale price was 259,800 yuan, and the pre-sale price of the optional sports kit was 278,800 yuan. It will be officially listed at this Guangzhou Auto Show.

　　As a series of N high-performance models, the design of the new Elantra N is extremely tense, and the fully blackened front and the newly designed X-shaped front enclosure give it a strong sense of movement. In details, you can see the red decorative lines of the whole car, Michelin PS4 series tires of 245/35 R19, red calipers with N logo, two large-size exhaust ports on both sides, and a fixed black spoiler.

　　When I arrived in the car, the new car still used a double screen, and the center console and seats still used a large area of leather and soft materials. However, the appearance of sports steering wheel, suede material and red start button will make all drivers’ blood boil.

　　In terms of power, it is equipped with an N-exclusive 2.0T GDI Flat Power engine with a wide range of power output technology, with a maximum power of 276 HP and a maximum torque of 40 KGF m (392 Nm), matching an 8-speed wet dual-clutch gearbox. At the same time, it is also equipped with N exclusive high-performance functions such as N Grin Shift, N Power Shift and N Track Sense Shift, which greatly improves driving pleasure. It is worth mentioning that after N Grin Shift is started, the vehicle will have a strong power in generate instantly, and the maximum output power can be increased by an additional 10 horsepower instantly, and the duration is as long as 20 seconds.

● New BMW 5 Series

　　On the eve of Guangzhou Auto Show in 2023, the team in front of car home photographed the billboard of BMW booth. It can be confirmed that the new BMW 5 Series will officially make its debut at Guangzhou Auto Show. According to the previous news, this release should be an extended version, and its back performance is worth looking forward to.

『Long-axis declaration chart』

『Scale version』

　　The new domestic BMW 5 Series long wheelbase version has been declared by the Ministry of Industry and Information Technology. The new car basically continues the design of overseas models. Compared with the current BMW 5 Series, the front face is more tough and looks dynamic and powerful. The new car will be equipped with a ring-shaped grille and boomerang daytime running lights as the latest design of BMW brand, but the giant "big nostrils" design of BMW 7 series is not used, and the overall shape is relatively restrained.

　　Semi-hidden door handle flush with the door, flat roof antenna make the side of BMW 5 Series look smoother, and the iconic "Hough Corner" of the rear door is integrated with the C-pillar. This idea is reflected in the current BMW 3 Series and 7 Series, and BMW has also added the details of the embossed number "5" on the black plaque, which is self-evident. According to the application information, in terms of body size, the length, width and height of the new car are 5175/1900/1520mm and the wheelbase is 3105mm respectively.

　　The obvious change in the tail is the lamp group, which adopts simple horizontal lines, making the visual effect more slender and exquisite, and redesigns the cover to better fit the vehicle shape on the profile.

　　The interior also adopts the latest family style, including the continuous screen design of 12.3-inch instrument +14.9-inch central control panel, and the new style sports steering wheel. The new car will be equipped with iDrive 8.5 system, and the intelligence will be further improved. IDrive 8.5 is developed based on Linux system, and the new system introduces the design of QuickSelect to improve the menu structure, so that drivers can access the set common functions quickly and conveniently. At the same time, BMW has also optimized the entrance logic of functions, and the entrance of applications and vehicle settings is more intuitive. The applications on the menu can also be adjusted according to the user’s usage habits and preferences.

　　Judging from the information previously declared, the declared model is 525Li version, and we can wait for a follow-up to see what other power versions will appear. In terms of power, the new car is equipped with a 2.0T engine with a maximum power of 156kW..

At [Autohome Jinhua Promotion Channel], we are giving back to the majority of consumers with eye-catching promotions. At present, this luxury car is undergoing an unprecedented price reduction promotion, with a maximum discount of 170,000 yuan, bringing real car purchase benefits to car buyers in Jinhua area. The starting price has been reduced to 239,800 yuan, which is very attractive. If you are interested in Jaguar XFL, don’t miss this rare opportunity, click "Chatty Car Price" in the quotation form now, and make your car purchase dream come true in a more cost-effective way.

The Jaguar XFL is a luxury sedan full of elegance, with a unique front design that incorporates the iconic elements of the Jaguar family. The iconic leopard-print air intake grille exudes power and sophistication, and with the streamlined body, it creates a sophisticated and sporty appearance. The overall style combines tradition and modernity, showing Jaguar’s perfect interpretation of luxury and performance. The body lines are smooth, and every detail reflects Jaguar’s excellence in design.

With its elegant side design, the Jaguar XFL presents a streamlined body profile. The body size is 5102mm x 1890mm x 1456mm, and the elegant proportions are unforgettable. With a wheelbase of 3100mm, it provides passengers with a spacious and comfortable interior space. The front and rear wheelbases are 1605mm and 1609mm respectively, ensuring driving stability and handling. The tire size is 245/40 R19, which shows Jaguar’s refined pursuit of detail and respect for speed, both visually and in actual driving. The wheel design style is simple and powerful, further strengthening the sporty temperament of the XFL.

The interior design of the Jaguar XFL is luxurious and refined, using exquisite leather materials to create a comfortable driving environment. The steering wheel is wrapped in leather, which not only feels delicate to the touch, but also supports manual and electric up and down + front and rear adjustment, providing excellent grip and operation convenience. The center console is equipped with an 11.4-inch large-size touch screen, integrated multimedia system, navigation and phone functions, which is full of technology and easy to operate. As for the seat, whether it is the main driver or the co-pilot, it is equipped with front and rear, backrest, high and low multi-directional adjustment, and the main driver’s seat also has electric memory function to ensure long-term driving comfort. In addition, the USB and Type-C interfaces in the car are reasonably distributed, and two interfaces are provided in the front row to meet the needs of passengers’ electronic devices and support the wireless charging function of mobile phones, further enhancing their practicality.

The Jaguar XFL is powered by a powerful 2.0T engine with a maximum power of 184 kW and a torque output of 365 Nm, capable of delivering 250 horsepower. With an 8-speed automatic transmission, the vehicle exhibits excellent performance and handling during acceleration and driving.

To sum up, Autohome owners are full of praise for the exterior design of the Jaguar XFL, considering it simple, stylish and atmospheric, full of youthful vitality. Owners especially appreciate its front face design, believing that the air grille of the China Grid complements the logo, highlighting the classic and modern sense of the Jaguar brand. This exterior design has undoubtedly become a source of confidence for car owners to drive and win our recognition of the Jaguar XFL design aesthetics.
